SF412A-LC-10KM
1.25G SFP 10km Transceiver
Gigabit 1310 nm FP module for 10 km single-mode links.
- 1.25Gbps
- DATA RATE
- 10 km
- REACH
- SFP
- FORM FACTOR
| Form Factor | SFP |
|---|---|
| Data Rate | 1.25Gbps |
| Wavelength | 1310 nm FP |
| Max Reach | 10 km |
| Fiber Type | Single Mode |
| Connector | LC Duplex |
| Diagnostics | SFF-8472 |
| Operating Temperature | 0 °C to +70 °C |
SFP transceiver compatible with the SFP Multi-Source Agreement, built around an LD driver, limiting amplifier, digital diagnostic monitor, 1310 nm FP laser and PIN photodetector. The data link reaches 10 km over 9/125 µm single-mode fiber at 1.25 Gbps through a duplex LC/UPC interface.
10 km Gigabit
1310 nm FP laser over 9/125 µm single-mode fiber, 1.25 Gbps data links
Hot-pluggable SFP
MSA footprint with duplex LC/UPC optical interface and metal enclosure
DDM supported
Digital diagnostic monitoring per SFF-8472, single +3.3 V supply
