W70AP
Wi-Fi 7 Dual-Band In-Wall Access Point
Wi-Fi 7 dual-band wall-plate AP with 3600Mbps aggregate, 160MHz bandwidth, dual 2.5G ports, MLO and 802.3af/at PoE.
- 3600Mbps
- MAX SPEED
- Wi-Fi 7
- WI-FI STANDARD
- 2x2.5G
- DUAL PORTS
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax/be |
|---|---|
| Max Speed | 2976 Mbps (2.4G 574 + 5G 2402) |
| MIMO | 2.4G: 2 streams, 2x2 MU-MIMO / 5G: 2 streams, 2x2 MU-MIMO |
| Client Capacity | 64 concurrent clients |
| Deployment | In-wall installation (standard 86mm junction box) |
| Ports | 1x 100M/1000M/2500M WAN port (Auto MDI/MDIX), 1x 100M/1000M/2500M LAN port (Auto MDI/MDIX), 1x Reset button, multi-color status LED |
| Form Factor | In-wall, 86 x 86 x 44 mm |
| Use Cases | Villas, dormitories, hotels, hotel rooms |
The W70AP is a dual-band Wi-Fi 7 wall-plate wireless access point delivering up to 3600 Mbps aggregate (688 Mbps on 2.4 GHz + 2882 Mbps on 5 GHz) with 160 MHz bandwidth. It features dual 2.5G Ethernet ports (one WAN, one LAN), MLO dual-band aggregation, MU-MIMO, OFDMA and fast roaming. Powered by standard 802.3af/at PoE through a single cable, it supports up to 8 SSIDs and is managed via Apollo cloud, mobile APP, local web or AC controller. Ideal for villas, dormitories, hotels and hotel rooms.
MAX SPEED
3600Mbps
WI-FI STANDARD
Wi-Fi 7
DUAL PORTS
2x2.5G
